UFO EVO Series

Solar outdoor lamp
UFO EVO Series
Luminous output 1700W

Spécifications techniques générales
Luminous rendering
Lumens
Angle
Norme
RA
Battery
Lighting color
Panneau solaire
Fréquence
Type de LED
Name of LEDs
Motion detector
Detection distance
Angle de détection
Insertion tube diameter
Programmed single mode
Charging duration
Durée d'éclairage
(Charge pleine)
Température de fonctionnement
Matériau
Certification
Poids
Garantie
Fiche Technique
Mode de fonctionnement
1700 watts
5100 Lumens
360°
IP65
> 70
12,8V / 12Ah au Lithium fer phosphate
3000k / 6000k
16,5V / 31W – Monocristallin
50 - 60 HZ
SMD5050
32 pieces
Yes, but not programmable
10 meters
65°
60~76mm
- 1st half hour:
  • Without passage (standby): 15% brightness
  • People passing by: 50% brightness
- Next time:
  • Without passage (standby): 50% brightness
  • People passing: 100% brightness
- Next time:
  • Without passage (standby): 30% brightness
  • People passing by: 80% brightness
- Next time:
  • Without passage (standby): 15% brightness
  • People passing by: 70% brightness
- Next 2h30:

  • Without passage (standby): 15% brightness
  • People passing by: 30% brightness
- Next 6 hours:
  • Without passage (standby): 15% brightness
  • People passing by: 25% brightness
- Last variation (until daybreak or battery exhaustion):
  • Without passage (standby): 15% brightness
  • People passing by: 50% brightness
3 to 5 Hours
2 jours (mauvais temps)
-20°C / +45°C
Aluminum alloy
CE & ROHS
6,2 kg
3 years
Fiche Technique PDF
Fiche Technique PDF
Luminous rendering
1700 Watts
Lumens
5100 Lumens
Angle
360 degrees
Norme
IP65
RA
> 70
Batterie
12,8V / 12Ah au Lithium fer phosphate
Panneau solaire
16,5V / 31W – Monocristallin
Fréquence
50 - 60 Hz
Lighting color
3000k / 6000k
Matériau
Aluminum alloy
Charging duration
3 to 5 Hours
Lighting duration
2 jours (mauvais temps)
Type de LED
SMD5050
LED Name
32 pieces
Motion detector
Yes, but not programmable
Detection distance
10 meters
Angle de détection
65°
Operating temperature
-20°C / +45°C
Programmed single mode
- First 3 hours: 100% constant
- Next 2 hours: 50% constant
- Last 8 hours: 20% without passage, 100% with passage
Insertion tube diameter
60~76mm
Dimensions produit
534 x 200 mm
Certification
CE & ROHS
Poids
6,2 kg
Garantie
3 years
Fiche Technique
